Carbon wand,Absorbing resonance couple structure

The carbon fiber has the characters of low mass and excellent rigidity, fiber structure is benefited for anti-resonance , It is the idea material to make the tonearm.

Effective oil damping design

The large damping oil cup guarantee tonearm to keep steady movement, JS-TA297 can supply the fresh, vivid sound, with excellent dynamic and bass performance.

Minimum tracking distortion

The large damping oil cup guarantee tonearm to keep steady movement, JS-TA297 can supply the fresh, vivid sound, with excellent dynamic and bass performance.

Reasonable Anti-Skating and counterweight control

The large damping oil cup guarantee tonearm to keep steady movement, JS-TA297 can supply the fresh, vivid sound, with excellent dynamic and bass performance.

Specification

    Effective length

    309mm

    Tracking Distortion

    <=0.5%

    Total weight

    585 g

    Pivot to Spindle Distance

    297mm

    Null points

    61.60mm/118.06mm

    Packing Size

    470*185*180mm

    Overhang

    12mm

    Cartridge weight

    min. 5g, max. 17g

    Packing Weight

    2.5 Kg

    Offset angle

    16.9 degree

    Effective mass

    13 g
